AC sensors, 220–240 V
Rod-Antenna On/Off Sensor, DIP Switch
HD02S-6 · HD02S-6 1
A 220–240 V AC on/off sensor with rod antenna, DIP switch and daylight sensor for ceiling lights and bulkheads, in 6 m and 4 m installation-height versions.
Market: EuropeRod antennaDIP switchDIP switch
220–240 V ACInput
3–6 m radiusDetection range
DIP switchControl
IP20IP rating
Highlights.
- Automatic on/off control with daylight sensor.
- Adjustable detection range, hold time and daylight threshold.
- Rod antenna and DIP switch setting.
- Versions for 6 m and 4 m installation height.
- Compact size, suited to ceiling lights and bulkheads; loop-in and loop-out wiring.
Tech specs.
HD02S-6 · HD02S-6 1Electrical
- Input voltage
- 220–240 V AC
- Control
- DIP switch
Detection
- Antenna
- Rod antenna
- Installation height
- 6 m / 4 m (by version)
- Detection range
- 3–6 m radius
- Settings
- Detection range, hold time, daylight threshold
Environment
- Operating temperature
- −20 °C to +60 °C
- IP rating
- IP20
Mechanical
- Wiring
- Loop in and loop out
Compliance
- Marks
- TÜV · CE · RED · RoHS · IP20
Warranty
- Warranty
- 5 years
Models & ordering
| Model | Rating / option | Notes / dimensions |
|---|---|---|
| HD02S-6 | ||
| HD02S-6 1 |
