On Off Control Microwave Motion Detector Remote Setting UFO Highbay Light

Place of Origin China
Brand Name HAISEN
Certification CE RoHS
Model Number HD415SR
Minimum Order Quantity 100PCS
Price Negotiation
Packaging Details Bubble pack, paper flat, outer carton.
Delivery Time 1-3 days for sample order, 1-2 weeks for bulk order
Payment Terms L/C, T/T, Western Union
Supply Ability 100000pcs per mouth
Product Details
Operating Voltage 120-277VAC Stand-by Power <1W
Detection Area 100%75%50%25% Hold Time 5s/30s/1min/5min/10min/20min
Microwave Power <0.3mW Microwave Frequency 5.8GHz±75MHZ100
High Light

microwave switch occupancy sensor

,

light on off sensor

Leave a Message
Product Description

On/Off Control Microwave Motion Sensor Remote Setting UFO Highbay light





Features:

  • On/off sensor for UFO highbay light.
  • Standby power<1W.
  • Have passed CE, RoHS certificate.
  • Remote control setting.
  • 5 years warranty.



Detailed Product Description:

Operating voltage 120~277VAC 50/60Hz
Switching capacity

120V,Max,200W(Control gear) Max.400W(Incandescent lamp)

277V,Max,400W(Control gear) Max.800W(Incandescent lamp)

Standby power <1W
Detection area 100%/75%/50%/25%
Hold-time 5s/30s/1min/3min/5min/10min/20min/30min
Daylight threshold 2Lux/10Lux/30Lux/50Lux/80Lux/20Lux/Disable
Microwave frequency 5.8GHz±75MHz
Microwave power <0.3mW
Interfaces 6-pole pluggable clamp terminal(L,N,PG,PG,N,L’) for 1.5mm 2 cable
Mounting height Max.15m(ceiling mounted);Max.3m(wall mounted)
Detection range Max.ø14m(ceiling mounted);Max.20m(wall mounted)
Operating temperature -20°C~+60°C
IP rating IP20



Wiring Diagram

Mechanical Structure(mm)

Detection Coverage:

Function Demo:

Application
