IP20 6m High Microwave Sensor Light On Off Sensor Max 400W Switching Capacity

Place of Origin CHINA
Brand Name HAISEN
Certification TUV RED CE
Model Number HD01S-6
Minimum Order Quantity 100PCS
Price Negotiable
Packaging Details Bubble pack, paper flat, outer carton.
Delivery Time 1-3 days for sample order, 2-3 weeks for bulk order
Payment Terms L/C, T/T, Western Union
Supply Ability 200,000pcs Per Month
Product Details
Operating Voltage 220-240 VAC 50/60Hz Mounting Height Max.6m
Function On/off Interfaces 4-pole Pluggable Clamp Terminal(L,N,N,L’) For 1.5mm2 Cable
Detection Angle 30°-150° Switching Capacity Max.400W
Hold Time 5s/90s/5min/15min Color White
IP Rating IP 20 Lifetime 50000 Hours
High Light

microwave motion detector

,

light on off sensor

Leave a Message
Product Description

ON/OFF Detector with Microwave Module 16M range with 6M Height Daylight Function Sensor for Ceiling light/Tri-Proof light in Office or Corridor



Features:

1. Movement detector to automatically control the light on/off with microwave module.

2. Daylight function to intelligently control the light off even detect movement when ambient daylight is sufficient.

3. Detection area, hold time and daylight sensor could be precisely set by DIP switch.

4. Different choices of parameters to provide more options for different situations.

5. Compact design and basic microwave motion sensor for widely used on many structures of light like ceiling light, tri-proof light and some linear light.

6. 4-pole pluggable clamp terminal (L,N,N,L') for 1.5mm² cable.

7. Operating voltage of 220-240VAC.

8. Built-in installation method to make the light more aesthetic without exposing any part.





Specifications:





Input Operating Voltage 220-240VAC 50/60Hz
Stand-by Power ≤0.5W
Output Switching Capacity Max.400W

Sensor Parameters

Hold Time 5s/90s/5min/15min
Detection area 10% / 50% / 75% / 100%
Daylight Threshold 2Lux/10Lux/50Lux/Disable
Mounting Height Max.6m(ceiling mounted);
Detection Range Max.16m(ceiling mounted);

Wireless

Parameters

Operating Frequency 5.8 GHz ±75 MHz
Switch Control 0N/0FF

Operating Environment

Operating Temperature -20℃~+60℃
Certificate Certificate TUV RED CE
Others Wiring Method 4-pole terminal (Input grey L. N. Output grey N. L’)
IP Rating IP20 (Built-in)
Installation Size 80.2*36.6*23mm
Packaging Bubble bag +Outer Carton(K=A)
Life 50000h





   ON/OFF                Daylight sensor         Detection area              Hold Time            5 yearsWarranty





IP20 6m High Microwave Sensor Light On Off Sensor Max 400W Switching Capacity 0

Wirng diagram:

4-pole pluggable clamp terminal(L,N,N,L’) for 1.5mm2 cable



Dimensions:

Small design & basic Micorwave Motion Sensor for easily installation and widely using in the smart lighting control industry.





Dip switch settings:

    Detection area                           Hold-time                      Daylight threshold



   Detection area means            Hold time means the           Daylight sensor priors

   detection coverage. It             time period the lights         to motion sensor. Set

   can be adjusted by                 will be ON after the             threshold for specific

   combining DIP                        last detection.                     needs. If disable, only

   switches for specific                                                          motion sensor works.

   application.





Function Demo:

1. Automatically ON/OFF function:
Light on when detect movement and off after people leave at night. Applications: Corridor, Staircase.



With sufficient daylight,                               With insufficient daylight,when                 After last detection,the light will be

even when motion                                       motion detected,light ON.                         dimmed down to the stand-by

detected, light remains OFF.                                                                                         dimming level after holdtime.



2. No Daylight Function

The daylight threshold is set to "Disable":

Light on when detect movement. After people leave, light off after after hold on time.
Applications: Dim places such as Basement Parking,Underpass.





Installation Method

1. The detected surface cannot be shielded by metal objects.

2. Make sure the microwave module is completely exposed outside.
3. The detection surface of the sensor module shall be installed facing the detection area.



Application:



Microwave can penetrate walls or glass thinner than 20cm and attenuate if thicker than 20cm. It's very suitable for indoor installation such as office, corridor etc.
