Customized Sensitivity Ceiling Mount Motion Detector Adjustable Time – Delay

Place of Origin China
Brand Name HAISEN
Certification CE
Model Number HD05S
Minimum Order Quantity 100PCS
Price USD3.7-4.6/PCS
Packaging Details Bubble pack, paper flat, outer carton.
Delivery Time 1-3 days for sample order, 1-2 weeks for bulk order
Payment Terms L/C, T/T, Western Union
Supply Ability 100000pcs per month
Product Details
Operating Voltage 220~240 VAC 50/60Hz Switching Capacity Max.400W(Control Gear) Max.800W(Incandescent Lamp)
Mounting Height Max.6m(ceiling Mounted) Detection Range Max.ø14m(ceiling Mounted)
High Light

microwave pir detector

,

external microwave sensor

Leave a Message
Product Description

Customized Sensitivity Ceiling Mount Motion Detector Adjustable Time – Delay

Detailed Product Description

   Operating voltage    220~240 VAC 50/60Hz
   Switching capacity    Max.400W(Control gear) Max.800W(Incandescent lamp)
   Stand-by power    ≤0.5W
   Detection area    10%/50%/75%/100%
   Hold time    5s/90s/5min/15min
   Daylight threshold    2Lux/10Lux/50Lux/Disable
   Microwave frequency    5.8GHz ±75MHz
   Microwave power    <0.3mW
   Mounting height    Max.6m(ceiling mounted)
   Detection range    Max.ø14m(ceiling mounted)
   Detection angle    30°-150°
   Operating temperature    -20°C~+55°C
   IP rating    IP20
   Life time    50,000 hours
   Warranty    5 years



Wiring diagram

Mechanical structure(mm)

DIP Switch Setting

Detection coverage

Demo



Application
