Empty Load 63V LED Motion Sensor Driver 10% 30% Stand By Dimming Level

Place of Origin China
Brand Name HAISEN
Certification CE
Model Number HT19V-I
Minimum Order Quantity 100PCS
Price Negotiable
Packaging Details Bubble pack, paper flat, outer carton.
Delivery Time 1-3 days for sample order, 1-2 weeks for bulk order
Payment Terms L/C, T/T, Western Union
Supply Ability 200,000pcs per month
Product Details
LED Driver 18W Isolated LED Driver Certificate CE
Input Voltage 220~240VAC 50/60Hz Input Power 22W(Max.)
Input Current 0.07A Max. Output LED Voltage 24-52V
Output LED Power 18W Max. Output LED Current 0.3A/0.35A±5%
Function Dimmable Driver And Sensor Warranty Officially 3 Years, Could Be 5 Years
High Light

63V LED Motion Sensor Driver

,

0.07A Motion Sensor Driver

,

63V 18w LED Driver

Leave a Message
Product Description

Empty Load 63V LED Motion Sensor Driver 10% 30% Stand By Dimming Level



Empty Load 63V LED Driver & Sensor 2-in-1 Max. 18W Microwave Motion Detector 6mHx14mD



HT19V-I is a Flicker-Free 220-240VAC 18W LED Driver&Microwave Sensor 2-in-1 Isolated Solution with 24-52V Output Voltage and 6m(H) x 14m(D)  Mounting Height and Detection Range



Features:

1. Flicker-free Isolated Solution;

2. Output Power 18W max. with Voltage of 24-52V

3. Optional Output current of 0.3A/0.35A for different projects.

4. Max. mounting height x detection range: 6M x 14M.

5. Empty Load voltage of 63V max.

6. Optional detection area, hold time, stand-by dimming level, stand-by period and daylight threshold.

7. Efficiency of 85%

8. Abnormal protection SCP: Auto recovery, OVP, OCP, OTP



Product Description

   Input voltage    220~240VAC 50/60Hz
   Input current    0.07A Max
   Input power    22W Max
   Detection area    50%/100%
   Hold time    5s/60s/ 5min/10min
   Daylight threshold    2Lux /10Lux /50Lux/Disable
   Stand-by period    0s/10s/10min /+∞
   Stand-by dimming level    10%/30%
   Microwave frequency    5.8GHz±75MHz
   Microwave power    <0.3mW
   Detection angle    30°-150°
   Mounting height    Max.6m
   Detection range    Max.ø14m
   Output LED current    0.3A/0.35A±5%
   Output LED voltage    24-52V
   Output LED power    18W Max.
   Empty load voltage    ≤63V
   Power factor    >0.9
   Efficiency    80% (Max.)
   Operating temperature    Ta: -20°C+50°C Tc: 80°C
   Abnormal protection    SCP:Auto recovery,OVP,OCP,OTP
   EMC standard    EN55015
   Safety standard    EN61347-1 EN61347-2-13 EN60598-1
   IP rating    IP20
   Life time    30,000 hours
   Warranty    3 years

Empty Load 63V LED Motion Sensor Driver 10% 30% Stand By Dimming Level 0

Detection Range

This figure indicates the maximum distance at the highest mounting height with 100% sensitivity.

Typical installation height 2.5-6m.



Mechanical structure

With eight DIP switch poles to set all parameters

With two DIP switch poles to choose different output current

With two installation hole, easily fixed to the lighting fixture for end user.



Wiring diagram

Two poles to connect with power supply (220-240VAC)

Two poles to connect with LED Light



Dimensions (mm)



DIP Switch Setting



Detection area  Hold-time     Daylight threshold   Stand-by period  Stand-by dimming level

In this area,          The period of      Definition of the           The period of light       The definition of
movement will      light keeping       ambient brightness;     keeping low output      low output in the
be detected         100% brightness   only when the              before it's                     standby period.
and able to           after moving        ambient brightness      completely
trigger the            objects leave the  is lower than the         switched off. When
sensor. 100%        detection area.     preset specific lux       it's preset as"∞“,
detection area                                  amount, the sensor      the light always
is also known                                   will work; when it's       keep at low output
as the strong                                    preset as "disable",       if no movement in
sensitvity.                                         the sensor works          the detection area

                                                         everytime it detects      and doesn't turn off.
                                                         motion regardless
                                                         the ambient brightness.

Daylight Priority

With Daylight priority function, HT19V-I is able to differentiate artificial light brightness
from natural light after installed inside the fixture, and automatically turn off light when
ambient brightness exceeds preset lux level.



Precondition of Daylight priority:
1. Standby period is +∞;
2. Standby dimming level is on 10% or 30%;
3. Daylight threshold is on 2Lux, 10Lux or 50Lux.



Application Demo

1. Automatically ON/OFF function:

Light on when detect movement and off after people leave at night. Applications: Corridor, Staircase.
The daylight threshold is set to "2lux,10lux,50lux"



With sufficient daylight,                 With insufficient daylight,             After the last detection and
even when motion detected,          when motion detected, light ON.   the present hold time
light remains OFF.                                                                               elapsed, light OFF.

2. No daylight function
The daylight threshold is set to "Disable".
Light on when detect movement, After people leave, Light off after stand-by period.
Applications: Dim places such as Basement Parking, Underpass.



When motion is detected,              After people leave the detection    After the last detection and
the sensor will switch on the         area, light remains 100%                the present hold time
light to 100% brighteness.             brightness within hold time.          elapsed, light OFF.

3. Function Demo - Dimmable control/Corridor function



With sufficient daylight,   With insufficient           After last detection,        After the stand-by
even when motion           daylight, when motion  light will be dimmed       period, light OFF.
detected, light remains    detected, light ON.       down to the stand-by
OFF.                                                                     dimming level (10% or

                                                                            30%) after holdtime.

Installation Method:



User Notes:

1. Suitable for indoor installation to avoid false triggering due to external factors such as rain, wind or tree swing.
2. Shall not be installed in the place with all four metal shelters and small space (such as galvanized-iron roof ).
3. Shall note be mounted installation, so as to avoid false trigger caused by the lamp itself shaking.
4. Shall not be installed next to large operating machines such as ventilator/ceiling fan to avoid false triggering caused by machine vibration.
